Electric Counter Balance Forklift

If you have any questions, please feel free to contact us.

Send mail

Ask for a quote

Share to：

PRODUCT INTRODUCTION

The CPD-10~30 is a cost-effective series of electric forklift with combination of the traditional Internal Combustion forklift and lithium-iron powered electric forklift, it has the characteristics of large driving space and comfortable operation. The standard configuration is lithium iron phosphate (LFP) battery with efficient fast charging. Optional different battery capacities: the standard configuration is 80V200Ah.optional 80V300Ah and 400Ah.Standard full AC control system and optional fleet management system. The truck adopts similar design of the Internal Combustion forklift with spacious operation space and comfort. The mast system, front and rear axles as well as the durability of chassis like traditional Internal Combustion forklift. The truck combined the durability of Internal Combustion forklift with layout advantage of Li-iron electric forklift, so that the truck's weight is light and gravity center is optimized, therefore the overall energy consumption is effectively improved.

Specification

Model		CPD-10	CPD-12	CPD-15	CPD-18	CPD-20	CPD-25	CPD-30
Drive Power		Electric	Electric	Electric	Electric	Electric	Electric	Electric
Drive Model		Siting	Siting	Siting	Siting	Siting	Siting	Siting
Rate Loading Capacity	Kg	1000	1200	1500	1800	2000	2500	3000
Loading Center	N	500	500	500	500	500	500	500
Wheel Base(F/R)	mm	820/810	820/810	950/810	950/810	950/810	950/810	1020/990
Weight
Service Weight(With battery)	kg	1260	1690	2700	2750	2800	3250	4300
Wheel
Tire		Solid Tire	Solid Tire	Solid Tire	Solid Tire	Solid Tire	Solid Tire	Solid Tire
Front Wheel Size	mm	16*6-8	16*6-8	6.00-9	6.00-9	6.00-9	20*7-10	23*9-10
Rear Wheel Size	mm	15*4 1/2-8	15*4 1/2-8	5.00-8	5.00-8	16*6-8	16*6-8	18*7-8
Size
Tile Angel(F/R)	%	6/12	6/12	6/12	6/12	6/12	6/12	6/12
Mast Lower Heigh	mm	2050	2050	2070	2070	2070	2070	2090
Free lift(with extend mast)	mm	105	105	105	105	105	105	105
Standard Mast Maxim lifting Heigh	mm	3000	3000	3000	3000	3000	3000	3000
Maxim Heigh with extand Mast	mm	3900	3900	3900	3900	3900	3900	4255
Overhead guard height	mm	1860	1860	2010	2010	2010	2010	2100
Overall Length	mm	1850	1850	2280	2280	2280	2360	2600
Overall Width	mm	970	970	1090	1090	1090	1130	1240
Fork Size	mm	32/100/920	32/100/920	35/100/1070	35/100/1070	40/100/1220	40/122/1220	45/125/1220
Max inside of fork width	mm	870	870	945	945	945	945	1100
Mini Ground Clearance	mm	100	100	105	105	105	105	105
Mini Aisle Width	mm	3200	3200	3664	3664	3664	3750	4664
Mini Turning Radius	mm	1900	1900	2240	2560	2560	2480	2400
Performance
Drive Speed Load/unload	km/h	10/12	10/12	10/12	10/12	10/12	10/12	10/12
Lifting Speed Load/unload	mm/s	230/250	230/250	230/250	230/250	230/250	230/250	230/250
Max Climbly Ability Load/unload	%	6/12	6/12	10/15	10/15	10/15	10/15	10/15
Brake Types		Hydralic/Electric
Parking Types		Mechanical
Power
Drive Motor	kw	3	3	5.5	5.5	6.5	7.5	11
Lifting Motor	kw	4	4	5.5	5.5	6.5	7.5	14
Battery(Lead Acid)	V/AH	48/150	48/150	72/180		72/200	72/300	72/450
Battery(Li-ion)	V/AH	48/150	48/150	80/150	80/180	80/150	80/220	80V/280
Charger	V/A	48/30	48/30	48/30	80/100	72/50,80V/100	72/100,80V/150	72/150,80V/150
Other
Drive Controller		AC	AC	AC	AC	AC	AC	AC
Lifting Controller		AC	AC	AC	AC	AC	AC	AC
Steering Types		Hyduralic	Hyduralic	Hyduralic	Hyduralic	Hyduralic	Hyduralic	Hyduralic
Noise	dB(A)	80	80	80	80	80	80	80
